Multi-Language: English, Deutsch, French, Dutch, Spanish, Czech, Swedish, Russian, Hungarian, Norwegian, Portuguese, Italian, Polish, Danish and Finnish.
Quality: Genuine
System updates: Available (Free updates for lifetime!)
Internet connections: Available
Warranty: 12 months
Manufacturer: iCarsoft
Made in USA
Support OBDII Ten Modes of Operation.
- Read Live Data.
- Full ECU Diagnosis.
- Easy To Use with Silicone Keys.
- Battery Test.
- Auto identify technology can automatically identify model and year information in no time.
- Actuation Test / Bi-directory Test is used to access vehicle-specific subsystem and component tests.
- Support Freeze Frame of Fault Code functions.
Supported Automotive Protocols: ISO9141-2, ISO14230-2,ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN),SAE J2610,GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6
5 Hot Service Functions covering your daily maintenance needs.
- Oil Reset: Support service lamp reset.
- Electronic Throttle Control: Reset of the throttle valve adaptation values while clear or replace the throttle valve, As the same time we need to reset the accelerator grip adaptation values. Then start the engine and let the positions of the throttle valve and accelerator handle self-learn to restore the best matching values.
- ABS Bleeding: the ABS bleeding function to bleed the brake system to restore ABS brake sensitivity.
- Electronic suspension: In the following cases: before delivery (after the factory assembly), after replacing the control module, after repairs to the ESA system. (For example, after replacing the spring/shock absorber module), this function needs to be executed for suspension and calibration.
- Engine Idle: Adjust the engine speed at idle speed.
**The service functions vary by motorcycle’s specifics. Contact us anytime for more details.
Real time graphic live data
The MT PRO motorcycle scan tool supports live data stream. This motorbike scanner also gives you the details of the fault code so you don’t have to search it online. And you can simply select the code to have its definition in the Diagnostic Trouble Code (DTC) lookup library.
Full OBD2 test modes to fix most of emission issues
Full OBD2 Scanner contains all 10 modes and easily determines the cause of the check engine light. Read and Erase Code, On-Board Monitor Test (Mode 6), EVAP Test (Mode 8), O2 Sensor Test, Live Data, Freeze Frame Data, DTC Lookup, etc. iCarsoft MT PRO motorcycle reader supports one-click check, turns off the annoying Check Engine Light, and gets your ride back on the road.
Support History and Report printing.
User can quickly access previously tested vehicle systems, save, share, and print diagnostic reports
This scan tool gives you access to the “Feedback” function which provides customized repair suggestions from our certified professionals. Moreover, you can print out the diagnostic data on paper for future reference. Simply hook it up to a Windows PC.
Product Specifications:
Display: 7-inch TFT LCD, with 1024×600 resolution
Operating System: Android 8.1.0
Processor Quad Core: 1.3 GHz
Memory: 32GB
Connectivity: USB 2.0 / Wi-Fi (2.4GHz) /Bluetooth/OBDII
Audio Input: N/A
Audio Output: Buzzer & Speaker
OBD DLC Voltage Range: 9-18V , 3.7V/5000mAh lithium-polymer battery
Charges via: 5V DC power supply
Tested Battery Life: Around 5 hours of continuous use
Battery Charging Input: 5V / 2A
Power Consumption: 500mA (LCD on with default brightness, Wi-Fi on) @3.7 V
Operating Temp: 0 to 40°C (32 to 104°F)
Storage Temp: -20 to 70°C (-4 to 158°F)
Operating Humidity: 5% – 95% non-condensing
Dimensions: (W x H x D) 252mm X 160mm X 34.4mm (9.92inch X 6.3inch X 1.35inch)
Net Weight: ≈750g
